Total Chaos Fabrcation

UPPER CONTROL ARMS - TOYOTA HILUX REVO

2016-2022 TOYOTA HILUX REVO SUSPENSION

Urethane Bushing Pivot Uniball UCA
PART #96504
$967.27

2016-2022 TOYOTA HILUX REVO SUSPENSION1-01-Toyota-Hilux-Revo-race-truck-off-road-performance-suspension2-01-Toyota-Hilux-Revo-off-road-beach-race-truck-ocean-off-road3-01-Toyota-Hilux-Revo-underbelly-skid-plate-suspension4-01-Toyota-Hilux-Revo-dirty-race-truck-sand-dirt-off-road5-01-Toyota-Hilux-Revo-beach-off-road-sand-south-america-off-road
INSTALL INSTRUCTIONS



WHY

Lifting the front of a vehicle with a set of coilovers may be step one in gaining more off-road performance, however installing just an aftermarket shock can cause limitations without upgrading the Upper Control Arm too.

Adding 2-3'' of lift on the vehicle will compromise your Toyota's factory alignment specs from lost caster. Our UCA's are designed to add 3 degrees of caster - offering better straight line tracking, as well as improved high speed stability and cornering.

TC upper arms add component durability and allow for individual parts to be replaced including bushings and uniballs.

FEATURES

UCA's are designed with added caster to aid in retaining factory alignment specs when aftermarket lift kits are installed. This reduces the darting or wandering in the vehicle's steering when 2.5" -3" lift kits are installed.

Will work with all aftermarket brand shocks.

Urethane bushings reduce bushing deflection compared to stock rubber bushings.

4130 chromoly tubular upper control arms are 100% bolt on.

CNC tapered spindle adapters convert the factory ball joint to a 1" uniball for added component strength & maximum wheel travel.

TOTAL CHAOS includes 1" I.D. uniballs that feature a heat-treated stainless-steel ball & heat-treated stainless-steel race for maximum corrosion resistance and component longevity. These uniballs also feature a military grade PTFE woven fabric liner that helps prevent noise.

Custom profile upper and lower hi-misalignment spacers maximize droop wheel travel and are machined from heat treated 17-4 stainless steel.

Control arm pivots include zerk fittings to grease the bushings and inner sleeves without disassembly.

3 stage powder coat process includes a durable clear coat to provide a long lasting finish.

Hand crafted in the U.S.A.

Complete Grade 8 hardware kit is included.

Upper Control Arm fits: 2016 Hilux Revo, 2017 Hilux Revo, 2018 Hilux Revo, 2019 Hilux Revo, 2020 Hilux Revo, 2021 Hilux Revo, 2022 Hilux Revo, 2023 Hilux Revo.

PARTS INCLUDED

WHEEL & TIRE

16" Wheel: 16" x 8" | 4.5" backspace    Tire: 285/75R16

17" Wheel: 17" x 8.5" | 4.75" backspace    Tire: 285/70R17

SHOCK INFO


PART #: KNG-25001-349A

PART #: 6CT 009 1A

HEIM JOINT PIVOT UPGRADE
