CHROMOLY ADJUSTABLE REAR LINKS - LEXUS GX460

2010-2023 LEXUS GX460 REAR SUSPENSION
CHROMOLY ADJUSTABLE REAR LINKS
PART #86400
$1,641.44

2010-2023 LEXUS GX460 REAR SUSPENSION1-01-toyota-lexus-4Runner-GX470-GX460-adjustable-rear-links2-01-lexus-gx470-adjustable-rear-links3-01-5th-gen-4Runner-rear-links-king-3.0-bypass-rear-shocksDSC00925IMG_3499IMG_3501IMG_3504
CALL TO PLACE ORDER
INSTALL INSTRUCTIONS



FEATURES

- 100% bolt on system.

- Pan hard bar includes 3/4" heims on both ends making it fully adjustable.

- 1.5" more droop wheel travel over stock links when longer shocks are installed.

- Constructed from 1 1/4" .375 wall 4130 chromoly tubing for maximum strength.

- Includes urethane pivot bushings and zerk fitting for easy maintenance.

- Hi-misalignment spacers and hardware are included.

- Upper and lower links are designed to incorporate a heim joint on non-axle side making this rear link system adjustable in length. Ships pre-set to factory length.

PARTS INCLUDED

UPPER LINK - QTY: (2)

LOWER LINK - QTY: (2)

PANHARD BAR - QTY: (1)

NUT, 7/8"-14 RHT JAM - QTY: (4)

NUT, 8MM-1.25 FLANGE HEAD NUT - QTY: (2)

NUT, 3/4"-16 RHT JAM - QTY: (2)

HEIM SPACER, UPPER LINK - QTY: (4)

HEIM SPACER, LOWER LINK - QTY: (4)

HEIM SPACER, PANHARD BAR - QTY: (4)

INNER SLEEVE (LARGE HOLE) - QTY: (2)

INNER SLEEVE (SMALL HOLE) - QTY: (2)

UNIVERSAL BUSHING, HALF - QTY: (8)

ZERK FITTING, 1/4"-28 90 DEGREE - QTY: (4)

RHT 7/8" X 7/8" HEIM - QTY: (4)

RHT 3/4" X 3/4" HEIM - QTY: (2)

Please contact us for any replacement parts.




Home > Rear Accessories > LEXUS > 2010-CURRENT GX460

CHROMOLY ADJUSTABLE REAR LINKS - LEXUS GX460
2010-2023 LEXUS GX460 REAR SUSPENSION
CHROMOLY ADJUSTABLE REAR LINKS
PART #86400
$1,641.44

CALL TO PLACE ORDER
INSTALL INSTRUCTIONS


FEATURES

- 100% bolt on system.

- Pan hard bar includes 3/4" heims on both ends making it fully adjustable.

- 1.5" more droop wheel travel over stock links when longer shocks are installed.

- Constructed from 1 1/4" .375 wall 4130 chromoly tubing for maximum strength.

- Includes urethane pivot bushings and zerk fitting for easy maintenance.

- Hi-misalignment spacers and hardware are included.

- Upper and lower links are designed to incorporate a heim joint on non-axle side making this rear link system adjustable in length. Ships pre-set to factory length.

PARTS INCLUDED

UPPER LINK - QTY: (2)

LOWER LINK - QTY: (2)

PANHARD BAR - QTY: (1)

NUT, 7/8"-14 RHT JAM - QTY: (4)

NUT, 8MM-1.25 FLANGE HEAD NUT - QTY: (2)

NUT, 3/4"-16 RHT JAM - QTY: (2)

HEIM SPACER, UPPER LINK - QTY: (4)

HEIM SPACER, LOWER LINK - QTY: (4)

HEIM SPACER, PANHARD BAR - QTY: (4)

INNER SLEEVE (LARGE HOLE) - QTY: (2)

INNER SLEEVE (SMALL HOLE) - QTY: (2)

UNIVERSAL BUSHING, HALF - QTY: (8)

ZERK FITTING, 1/4"-28 90 DEGREE - QTY: (4)

RHT 7/8" X 7/8" HEIM - QTY: (4)

RHT 3/4" X 3/4" HEIM - QTY: (2)

Please contact us for any replacement parts.
