LAND CRUISER 200 SERIES SPINDLE GUSSETS

2008-2021 TOYOTA LAND CRUISER 200 SERIES ACCESSORIES

WELD-ON SPINDLE GUSSETS

PART #59699

$66.55

2008-2021 TOYOTA LAND CRUISER 200 SERIES ACCESSORIES

INSTALL INSTRUCTIONS

WHY

Must have reinforcement! Whether intentional or not, harsh impacts are a part of off-road. As speeds increase and the terrain gets tougher, the factory Toyota spindles are prone to bending during a big hit. TOTAL CHAOS weld-on spindle gussets reinforce the spindle upright to prevent damage to the knuckle.

FEATURES

- Must have reinforcement for anyone who wants to play in the dirt!

- Strengthens spindle uprights. Prevents the knuckle from bending or breaking during hard unexpected impacts.

- 1/8'' prebent laser cut mild steel brackets.

- Welding and grinding are required to install.Factory spindles are forged, not cast and gussets can be MIG or TIG welded directly to them.

- Trucks running factory back spacing wheels must run 1.25'' wheel spacers.

- Kit includes 1 pair of gussets for driver and passenger side.

- Designed for use with TC uniball upper control arms. May not be compatible with other manufacturers' control arms and hardware.

- These are model specific. Check your year, make & model.

PARTS INCLUDED

PAIR OF SPINDLE GUSSETS - QTY: (1)

LAND CRUISER 200 SERIES SPINDLE GUSSETS

2008-2021 TOYOTA LAND CRUISER 200 SERIES ACCESSORIES

WELD-ON SPINDLE GUSSETS

PART #59699

$66.55

INSTALL INSTRUCTIONS

WHY

Must have reinforcement! Whether intentional or not, harsh impacts are a part of off-road. As speeds increase and the terrain gets tougher, the factory Toyota spindles are prone to bending during a big hit. TOTAL CHAOS weld-on spindle gussets reinforce the spindle upright to prevent damage to the knuckle.

FEATURES

- Must have reinforcement for anyone who wants to play in the dirt!

- Strengthens spindle uprights. Prevents the knuckle from bending or breaking during hard unexpected impacts.

- 1/8'' prebent laser cut mild steel brackets.

- Welding and grinding are required to install.Factory spindles are forged, not cast and gussets can be MIG or TIG welded directly to them.

- Trucks running factory back spacing wheels must run 1.25'' wheel spacers.

- Kit includes 1 pair of gussets for driver and passenger side.

- Designed for use with TC uniball upper control arms. May not be compatible with other manufacturers' control arms and hardware.

- These are model specific. Check your year, make & model.

PARTS INCLUDED

PAIR OF SPINDLE GUSSETS - QTY: (1)
