EXPEDITION SERIES STOCK LENGTH LOWER CONTROL ARMS - SINGLE SHOCK

2003-2009 TOYOTA PRADO 120 LOWER CONTROL ARMS

PERFORMANCE LOWER A-ARM
PART #86555-E-NSS
$2,298.98

2003-2009 TOYOTA PRADO 120 LOWER CONTROL ARMS86555-E-NSS_Image_286555-E-NSS_Image_386555-E-NSS_Image_4
CALL TO PLACE ORDER
INSTALL INSTRUCTIONS



WHY

Stock ball joints and rubber bushings eventually wear out and must be replaced. Sloppy steering and uneven tire wear are common when these parts become worn out or damaged. You cannot individually order bushings or ball joints from Toyota for the factory lower control arms.

LCAs are 100% bolt-on and upgrade ball joints to a 1'' stainless steel uniball maximizing strength. Rubber bushings are replaced with urethane bushings to provide better off road trail handling and steering response. Less bushing deflection allows the vehicle steering to be more responsive at higher speed on and off road.

These fully rebuildable lower control arms are hand crafted from 4130 chromoly construction making them much stronger than the stock units. Available with single shock tabs or dual shock capability to maximize vehicle dampening control and performance.

FEATURES

- Light weight. Maximum ground clearance. Fully rebuildable. Bolt on.

- Pocket added at the coilover shock tabs maximizes clearance allowing for a wider range of shocks to be used - up to 3.0". Will work with all brands of aftermarket shocks.

- Billet CNC machined uniball cup houses a 1'' 100% stainless steel uniball that upgrades the factory ball joints for greater articulation and strength.

- Integrated steering stop tabs retain factory turning angles.

- Urethane pivot bushings reduce deflection compared to a rubber bushing offering a tigher steering feel. Zerk fittings allow for easy maintenance.

- 4130 chromly laser cut plates are fully boxed and include internal gussets.

- Stock length replacement lower A-arm - SINGLE SHOCK ONLY.

- Three stage powder coat includes a durable clear coat.

- 100% MADE IN U.S.A.

PARTS INCLUDED







EXPEDITION SERIES STOCK LENGTH LOWER CONTROL ARMS - SINGLE SHOCK
2003-2009 TOYOTA PRADO 120 LOWER CONTROL ARMS

PERFORMANCE LOWER A-ARM
PART #86555-E-NSS
$2,298.98

CALL TO PLACE ORDER
INSTALL INSTRUCTIONS



WHY

Stock ball joints and rubber bushings eventually wear out and must be replaced. Sloppy steering and uneven tire wear are common when these parts become worn out or damaged. You cannot individually order bushings or ball joints from Toyota for the factory lower control arms.

LCAs are 100% bolt-on and upgrade ball joints to a 1'' stainless steel uniball maximizing strength. Rubber bushings are replaced with urethane bushings to provide better off road trail handling and steering response. Less bushing deflection allows the vehicle steering to be more responsive at higher speed on and off road.

These fully rebuildable lower control arms are hand crafted from 4130 chromoly construction making them much stronger than the stock units. Available with single shock tabs or dual shock capability to maximize vehicle dampening control and performance.

FEATURES

- Light weight. Maximum ground clearance. Fully rebuildable. Bolt on.

- Pocket added at the coilover shock tabs maximizes clearance allowing for a wider range of shocks to be used - up to 3.0". Will work with all brands of aftermarket shocks.

- Billet CNC machined uniball cup houses a 1'' 100% stainless steel uniball that upgrades the factory ball joints for greater articulation and strength.

- Integrated steering stop tabs retain factory turning angles.

- Urethane pivot bushings reduce deflection compared to a rubber bushing offering a tigher steering feel. Zerk fittings allow for easy maintenance.

- 4130 chromly laser cut plates are fully boxed and include internal gussets.

- Stock length replacement lower A-arm - SINGLE SHOCK ONLY.

- Three stage powder coat includes a durable clear coat.

- 100% MADE IN U.S.A.

PARTS INCLUDED
